This 800-ton 20-layer hydraulic hot press is a heavy-duty plywood pressing equipment designed for standard 4×8ft plywood boards. Equipped with dual hydraulic pump system, six main oil cylinders and DELTA PLC automatic control system, this oil heating hot press realizes fast closing, uniform pressure distribution and stable continuous production. As a CE-certified woodworking machine, it is widely applied in medium and large-scale plywood factories for construction plywood, furniture plywood and decorative plywood mass production.
Technical Item | Specific Parameter |
|---|---|
Nominal Pressure | 800 Tons |
Processing Layers | 20 Layers |
Hot Platen Quantity | 21 Pcs |
Hot Platen Size | 1370×2700×52mm (Double in & Double Outlet) |
Board Feeding Direction | Transverse |
Finished Board Size | 1220×2440mm (4×8ft Standard Size) |
Main Cylinder Configuration | 6 Pcs, Φ260mm |
Quick Lift Cylinder | 2 Pcs, Φ120mm |
Cylinder Stroke | 1050mm |
Max Working Pressure | ≤25MPa |
Closing Time | 10 Seconds |
Low Pressure Pump | 100 Flow, 22KW Power, ≤3MPa |
High Pressure Pump | 25 Flow, 11KW Power, ≤25MPa |
Control System | DELTA PLC + Schneider Electrical Appliances |
Main Steel Plate | 30mm × 4 Pcs Thickened Steel |
Frame Structure | Assembled Heavy-duty Frame |
Overall Dimension | 3600*1370*5600mm |
Machine Weight | 45 Tons |
This plywood hot press adopts separated low-pressure and high-pressure pump design. The 22kW low-pressure pump realizes rapid lifting, while the 11kW high-pressure pump provides stable molding pressure. Cooperated with two Φ120mm quick lift cylinders, the machine completes closing action within 10 seconds. Compared with single-pump hot presses, it effectively shortens pressing cycle and increases daily plywood output by 18%-22%.
The whole machine weighs 45 tons, equipped with four pieces of 30mm thick main steel plates. The assembled frame disperses 800-ton pressure evenly to avoid structural torsion and steel plate deformation during long-term high-load operation. It keeps pressing flatness stable for more than 10 years, reducing later maintenance and replacement costs for plywood factories.
21 pieces of thickened hot platens adopt double oil inlet and double oil outlet circulation design. The internal oil circuit is reasonably arranged to ensure the surface temperature difference of the hot platen is controlled within ±2℃. It effectively eliminates plywood bubbles, degumming and uneven gluing problems, greatly improving the yield rate of Grade A plywood.
The control core adopts DELTA PLC intelligent system, matched with Schneider electrical components. The equipment supports one-key start, pressure setting, time reservation and automatic pressure maintaining. The sensitive control system reduces manual operation errors and realizes unmanned continuous pressing production.
Applicable Board: Standard 1220×2440mm plywood, including construction plywood, furniture plywood, packaging plywood;
Feeding Method: Transverse feeding, convenient for docking with automatic loading and unloading production line;
Factory Scale: Medium and large plywood factories, supporting mass continuous production;
Matched Equipment: Veneer peeling machine, glue spreader, veneer dryer, edge trimming machine and sanding machine to form a complete plywood production line.
Founded in 2011, with more than 15 years of woodworking machinery R&D and manufacturing experience. The factory covers an area of 604 square meters, has professional mechanical processing workshops and complete testing equipment, and has stable cooperative customers in more than 6 countries.
All hot press machines have passed CE certification (Certificate No. HT23DC-021033R), comply with EU 2006/42/EC Machinery Directive and 2014/35/EU Low Voltage Directive. Implementation standards include EN ISO 12100:2010, EN 60204-1:2018, which meet international export inspection requirements.
Production line layout design according to factory site;
Engineer on-site installation, commissioning and worker operation training;
7×24 hours global online after-sales technical support;
Complete spare parts supply to reduce factory downtime.
The nominal pressure is 800 tons, and the safe working pressure shall not exceed 25MPa. We suggest customers keep the working pressure within the safe range to extend machine service life.
Yes. We can customize hot platen size, layer quantity, feeding mode and heating system according to customer's plywood production requirements.
The standard model has a delivery cycle of 30-45 working days. Customized equipment will confirm the production cycle with customers separately.
We provide 12-month whole machine warranty, lifetime technical guidance, overseas on-site installation and training services, and global spare parts express delivery.
If you are looking for a stable, high-efficiency and low-maintenance plywood hydraulic hot press, please contact us. Our professional mechanical engineers will provide targeted production solutions and detailed quotation within 24 hours according to your factory output, board thickness and raw material conditions.
